Twitter| Business Type | Manufacturer, Exporter, Supplier |
| Brand Name | Enersol Biopower® |
| Country of Origin | India |
| Capacity | 100KW (125KVA) |
| Click to view more | |
Preferred Buyer From
| Location | India, South Africa, Nepal, Bangladesh, Myanmar |
Product Details
Auxiliary Power Required
4 HP
Biomass Consumption per Hour
150kg/hr.
Gas flow (NM3/hr.)
300NM³/hr.
Thermal Output At 100%
375,000Kcal/hr
Thermal Output At 80%
300,000 Kcal/hr.
Click Here to View Catalogue
ViewSpecifications
| Brand Name | Enersol Biopower® |
| Capacity | 100KW (125KVA) |
| Model Name | ESB-R BIO-100 |
| Model No. | ESB-R100 |
| Fuel | 100% Biomass |
| Type of Gasifier | Downdraft Gasifier |
| Man power required | 2-3nos |
| Auxiliary power required | 4hp |
| Biomass consumption per hour | 150kg/hr. |
| Gas flow (NM3/hr.) | 300NM³/hr. |
| Thermal output at 100% | 375,000Kcal/hr |
| Thermal output at 80% | 300,000 Kcal/hr. |
| Gasification temperature | 1050- 1100°C |
| Average gas calorific value | ≥1000 |
| Biomass feeding system | Manual / Automatic |
| Ash removal system | Manual |
| Ash content | 5-7% |
| start up | Auto ignition |
| Acceptable moisture in biomass | less than 20% |
| Material of construction | Mild Steel, Ceremic Brick & Stainless Steel |
| Water tank capacity | 3000ltrs. |
| Producer gas genset capacity | 100KW (125KVA) |
| Starter | 24V starter |
| Power factor | 0.8 P.F. |
| Governor | Electronic governor |
| Phase | Three phase |
| Amps per phase | 170amps/phase @100% 136amps/phase at 80% (three phase) |
| Frequency | 50Hz |
| Voltage | 415V |
| Engine Ignition system | Spark Ignition |
| Stroke | Four stroke engine |
| Bore x Stroke | |
| Rated speed | 1500RPM |
| No of cylinder | Six cylinders |
| Lube oil sump capacity | 22ltrs. |
| Cooling system | water cooled |
| Control panel | provided |
| Battery | Exide |
| Acoustic enclosure (canopy) | yes |
| Weight | 10-12ton |
| Size (Gasifier) | L32 x W20 x H25 (feet) |
Looking for "100KVA Biomass Gasifier" ?
